    ST3P-R High Quality Control Output 5A 220VAC Timer Delay Relay

     Product Name

     Time Relay

     Voltage

     DC12V-48V AC12V-380V50HZ

     Power Expend

     DC1.0W AC1.0VA

     Control Output

     5A220VAC

     Insulation Resistance

     DC500V 100MΩ

     Dielectric Strength

     BCC1500VAC BOC1000VAC

     Operating Temperature

     -10℃~50℃

     Location

     Zhejiang, China (Mainland)



    Type:

      time delay relay

    Dimension:

    57×41×84mm

    Work Form:

    Re-cycle on time

    Contact Form:

    1Z Delay Contact

    Contact Capacity:

    AC 250V 5A

    Contact Electrical Life:

    10×104

    Operation Temperature:

    ~5°c~+40°c

    Delay Accuracy:

    ≤0.5%

    Working Voltage:

    AC:50Hz,36V,110V,127V,220V,380V;DC:12V,24V

    Delay Specification:

    0.1S~12h

    Installation:

    Din Rail Type




    Hot Tags: ST3PR, manufacturers, suppliers, factory, Customized

    ST3P-R High Quality Control Output 5A 220VAC Timer Delay Relay

     Product Name

     Time Relay

     Voltage

     DC12V-48V AC12V-380V50HZ

     Power Expend

     DC1.0W AC1.0VA

     Control Output

     5A220VAC

     Insulation Resistance

     DC500V 100MΩ

     Dielectric Strength

     BCC1500VAC BOC1000VAC

     Operating Temperature

     -10℃~50℃

     Location

     Zhejiang, China (Mainland)



    Type:

      time delay relay

    Dimension:

    57×41×84mm

    Work Form:

    Re-cycle on time

    Contact Form:

    1Z Delay Contact

    Contact Capacity:

    AC 250V 5A

    Contact Electrical Life:

    10×104

    Operation Temperature:

    ~5°c~+40°c

    Delay Accuracy:

    ≤0.5%

    Working Voltage:

    AC:50Hz,36V,110V,127V,220V,380V;DC:12V,24V

    Delay Specification:

    0.1S~12h

    Installation:

    Din Rail Type
