    Digital temperature controller features



    1. Thermal resistance or thermocouple input and measuring range both can be set freely.

    2. Softwareadjust zero and full scale, temperature measuring of cold-end alone, amplifier constant-zero, display accuracy is better than 1.0%FS.

    3. The method of fuzzy theory combine with the traditional PID makes the temperature be controlled quickly and smoothly.

    4. The method of advanced PID parameter self-tuning saves a third time as compared with ordinary instrument.

    5. The output signal is optional: relay output, DC12V driver solid state relay, 4-20mA current.

    6. Alarm output: two circuit user-defined alarm output.



     Detailed image of temperature controller rex-c series



    Product Main Specifications:

    Model number

    External dimensions

    Perforation dimensions

    Output type

    Input type

    REX-C100

    48x48x100 mm

    45 0.50x45 0.50 mm

    Electromagnetic relay, SSR

    Thermocouple and RTD






    REX-C400

    48x96x100 mm

    45 0.50x92 0.50 mm

    Electromagnetic relay, SSR

    Thermocouple and RTD

    REX-C410

    96*48x100 mm






    REX-C700

    72x72x100 mm

    68 0.50x68 0.50 mm

    Electromagnetic relay, SSR

    Thermocouple and RTD






    REX-C900

    96x96x100 mm

    92 0.50x92 0.50 mm

    Electromagnetic relay, SSR

    Thermocouple and RTD


    Model number

    REX-C series

    Accuracy

    ±0.5% of full scale

    Supply voltage

    100-240Vac, 50/60 Hz

    Input types-Thermocouple

    K, J, R, S, B, E, N, T

    RTD

    Pt100, Cu50

    Voltage

    0-5V, 1-5V

    Current

    0-20mA, 4-20mA

    Output types

    Electromagnetic relay, SSR, current, SCR

    Power consumption

    Less than 5 VA

    Control method

    PID Control (with auto-tuning) or Self-tuning, or ON/OFF

    Setting method

    Touch switch

    Indication method

    8-segment 4-digital display and LED indication

    Alarms

    Deviation High, Low, High/Low, Band,Process High, Low Set value High, Low

    Sampling period

    0.5s

    Electromagnetic compatibility

    IEC61000-4-4 (Electrical fast transient burst), 4KV/5KHz; IEC61000-4-5 (Surge), 4kv

    Isolation voltage

    >=2300v among the terminal of power, relay contact and signal; >=600v between two isolated weak signal terminal

    Operating temperature

    0 to 50 ℃ (32 to 122 ℉)

    Operating humidity

    30-85% RH max, non-condensing

    Alias name

    REX-C pid temperature controller, intelligent temperature controller






    Hot Tags: REX-C100, manufacturers, suppliers, factory, Customized

    Product Main Specifications:

    Model number

    External dimensions

    Perforation dimensions

    Output type

    Input type

    REX-C100

    48x48x100 mm

    45 0.50x45 0.50 mm

    Electromagnetic relay, SSR

    Thermocouple and RTD






    REX-C400

    48x96x100 mm

    45 0.50x92 0.50 mm

    Electromagnetic relay, SSR

    Thermocouple and RTD

    REX-C410

    96*48x100 mm






    REX-C700

    72x72x100 mm

    68 0.50x68 0.50 mm

    Electromagnetic relay, SSR

    Thermocouple and RTD






    REX-C900

    96x96x100 mm

    92 0.50x92 0.50 mm

    Electromagnetic relay, SSR

    Thermocouple and RTD


    Model number

    REX-C series

    Accuracy

    ±0.5% of full scale

    Supply voltage

    100-240Vac, 50/60 Hz

    Input types-Thermocouple

    K, J, R, S, B, E, N, T

    RTD

    Pt100, Cu50

    Voltage

    0-5V, 1-5V

    Current

    0-20mA, 4-20mA

    Output types

    Electromagnetic relay, SSR, current, SCR

    Power consumption

    Less than 5 VA

    Control method

    PID Control (with auto-tuning) or Self-tuning, or ON/OFF

    Setting method

    Touch switch

    Indication method

    8-segment 4-digital display and LED indication

    Alarms

    Deviation High, Low, High/Low, Band,Process High, Low Set value High, Low

    Sampling period

    0.5s

    Electromagnetic compatibility

    IEC61000-4-4 (Electrical fast transient burst), 4KV/5KHz; IEC61000-4-5 (Surge), 4kv

    Isolation voltage

    >=2300v among the terminal of power, relay contact and signal; >=600v between two isolated weak signal terminal

    Operating temperature

    0 to 50 ℃ (32 to 122 ℉)

    Operating humidity

    30-85% RH max, non-condensing

    Alias name

    REX-C pid temperature controller, intelligent temperature controller
